ECOCON SOLID WALL SYSTEM
Fast, Economical and Quality Replacement to Masonry Blockwork and Dry Walls.
Application of ECOCON SOLID WALL provides substantial improvement in quality, safety, and durability of internal and external walls and internal partitions without cost increment. ECOCON SOLID WALLS are recommended for high-end residential buildings, schools, kindergartens, and other developments where safety, comfort and durability are essential.
TECHNICAL SPECIFICATIONS
Fire Rating for 100 mm wall, hours .................... 4
Sound Resistannce for 200 mm wall, dB ..........50
Weight per square meter, kg:
100 mm wall ................................................................50
150 mm wall .................................................................70
200 mm wall ................................................................90
U-value:
100 mm wall .............................................................0.99
150 mm wall ................................................................0.7
200 mm wall ............................................................0.54
ADVANTAGES
Fast Erection;
MEP pre-installed.
Absence of "knock-through" sound; increased acoustic proofing.
Extended Fire Rating; 4 hours for 100 mm wall.
Extended durability; Reinforced with galvanised steel.
Lightweight; 400 500 kg/m3 density of filling material.
COST SAVING
Saving on MEP installation - 40% less;
Saving on blocks wastage - 10% less;
Saving on foundation and RCC structure due
to low weight - up to 10%;
Saving on lintels (lintels are not required);
Saving on exact dimensions of door and window openings - possibility to place frames order at day one of construction process.
METHOD
Stage 1
LGS erection and MEP installation
Stage 2
Boards fixing
Stage 3
Filling walls with lightweight concrete
Stage 4
Finishing
Stage 5
Painting (tiling)
CERTIFICATES & APPROVALS
GALLERY
